Beschreibung
- 96kHz XCVI Core variable bit-depth up to 96bit, <0.7ms latency
- 48x Input Processing Channels
- Stereo Main LR Output
- 12x Mixes (Mono/Stereo, Aux/Group)
- 4x FX Sends
- 4x RackUltra FX Sends
- 6x Mono/Linkable Matrix Mixes
- 16x XLR Mic/Line Input Sockets
- 2x Stereo Line Input Sockets (each 2x TRS)
- 1x XLR Talkback Socket
- 12x XLR Output Sockets
- 2x TRS Output Sockets
- 1x AES3 Stereo Digital Output Socket
- 128×128 SLink Port for Everything I/O expansion and system connections
- 64×64 I/O Port for Option Cards (128×128 with SLink card fitted)
- Stereo Headphone Output
- 9 Capacitive Touchscreen
- 17x 100mm Motorised Faders
- 6x Customisable Channel Strip Layers
- 8x SoftKeys
- Configurable single/dual Footswitch Connection
- Configurable Chromatic Channel Meter LEDs
- IEC Mains Connection with Worldwide PSU
- RJ45 Network Socket for control
- 19 Rack Mountable (optional kit available)
- USB-A For stereo/multichannel audio record/playback and data (Stereo @48/96kHz, 24bit. 16 Channels @96kHz, 24bit. 32 Channels @48kHz, 24bit.)
- USB-B Audio interface for multichannel record/playback (32×32 @48/96kHz, 16/24bit)
- Input processing Trim, HPF, Gate/Expander, Parametric EQ, Compressor, Channel Delay
- Mix processing Graphic EQ, PEQ, Compressor, Channel Delay
- Fully patchable Insert points on all Input and Mix Channels
- 8x Multi-FX Engines with dedicated Stereo Return Channels and PEQ
- 4x RackUltra FX Engines with dedicated Stereo Return Channels and PEQ
- 2x 24 Channel or 1x 48 channel, zero latency, DEEP Automatic Mic Mixer
- 2x Real Time Analysers
- 300 Scene memories per Show
- Channel Safes, Global/Per-Scene Recall Filters
- FX, Processing, Channel, User Permissions, Input Patch Libraries
- 10 Configurable Users with Permissions to restrict operator access
- DAW Control emulation via USB or TCP/IP
- Compatible with ME personal monitoring range
- Remote control via free apps Windows/MacOS/iOS/Android
