- – Output voltage at 1000 Hz, 5cm/sec.: 6 mV
- – Channel balance at 1 kHz: 2 dB
- – Channel separation at 1 kHz: 23 dB
- – Channel separation at 15 kHz: 15 dB
- – Frequency range: 20-20.000 Hz
- – Frequency response: 20-18.000 Hz + 3 / – 2 dB
– FIM distortion at recommended tracking force, DIN 45.542: < 1% -Tracking ability at 315Hz at recommended tracking force: 80 µm - Compliance, dynamic, lateral: 9 µm/mN - Stylus type: Spherical - Stylus tip radius: R 18 µm - Equivalent stylus tip mass: 0,6 mg - Tracking force range: 2,0-4,0 g (20-40 mN) - Tracking force, recommended: 3,0 g (30 mN) - Tracking angle: 20° - Internal impedance, DC resistance: 750 Ohm - Internal inductance: 450 mH - Recommended load resistance: 47 kOhm - Recommended load capacitance: 200-600 pF - Cartridge colour, body/stylus: Blue/Blue - Cartridge weight: 18,5 g - Replacement stylus unit: DJ S
